Ceiling Accessories
Hook Hanger Bracket
Hook Hanger Bracket — EN 13964 compliant supply for hook-on systems from a single source.
Material
Hot-dip galvanized steel (DX51D+Z)
Dimensions
2.5 mm sheet, M6 / M8
Pack Contents
50 pcs/box
Standard
EN 13964
Certifications
- EN 13964
- EN 13501-1: A1
- ISO 9001 quality management
- CE (EU Construction Products Regulation)
Quick Answer
Hook Hanger Bracket is a component providing reliable installation in hook-on systems, declared under EN 13964. Produced in 2.5 mm sheet, M6 / M8 from Hot-dip galvanized steel (DX51D+Z), it offers fast and safe installation for professional teams.
Hook Hanger Bracket is a key installation component in hook-on systems. Manufactured in 2.5 mm sheet, M6 / M8 from Hot-dip galvanized steel (DX51D+Z), it delivers high strength and a long service life.
Suspends the ceiling system from the structural slab with millimetric level adjustment; compatible with hook-on.
Supplies panels, carriers and fixings in one package; a turnkey infrastructure for hook-on.
Contact us with your project dimensions, quantities and RAL colors; the metaltavan.com engineering team supports you from product selection to installation details.
| Material | Hot-dip galvanized steel (DX51D+Z) |
|---|---|
| Dimensions | 2.5 mm sheet, M6 / M8 |
| Pack Contents | 50 pcs/box |
| Standard | EN 13964 |
| Fire Class | A1 |
| System Compatibility | hook-on |
| Load / Performance | single hook load 1.0 kN |
| Surface | Galvanized |
- Offices and business centers
- Airports and transport hubs
- Industrial facilities
- Shopping malls and retail
- Hot-dip galvanized steel body
- High load capacity
- Corrosion-resistant surface
- Dimensionally matched to the panel system
- Project-specific length and quantity planning
Installation & Application
- 1 Survey the ceiling level; mark suspension points at max. 1200 mm centers.
- 2 Drill and anchor; fix M6 rods or 4 mm wires to the slab.
- 3 Fit level-adjustment clips and level the reference height for hook-on carriers.
- 4 Hang the main carriers on the clips; set spacings per the project grid layout.
- 5 Check all connections and safety wires; verify level tolerance of ±3 mm/m.
FAQ
Hook Hanger Bracket is manufactured from Hot-dip galvanized steel (DX51D+Z) and declared under EN 13964.
It works with metal ceiling systems including hook-on; consult us for the project-specific system list.
Installation is carried out by professional teams according to the manufacturer instructions; the 5-step summary on the product page can be used as a reference.
The product is in fire class A1 (under EN 13501-1).
Standard pack: 50 pcs/box. Dimensions: 2.5 mm sheet, M6 / M8. Contact our sales team for project-specific sizes.
3-5 working days for stock items; 2-3 weeks for project-specific production. Contact our sales team for current information.
